Anatomical S5 segmentectomy for regional cholangitis due to bile duct injury: versatile applications of indocyanine green (with video)

Introduction

Background

Iatrogenic injury to the biliary tract is a very severe complication that can affect both the quality of life and survival of patients (1). Among the many treatments available, the surgical resection of the affected hepatic segment has been described (2). This surgical intervention is very challenging and poses a significant challenge even for expert hepatobiliary and pancreatic surgeons.

Indocyanine green (ICG) is a virtually harmless molecule, approved by the Food and Drug Administration in 1959 (3). Following intravenous administration, it binds to alpha-1 lipoprotein, diffusing through all vascularized tissues in the body (4-6). Subsequently, ICG is taken up into hepatocytes by organic anion transporting polypeptide 1B3 and Na⁺/taurocholate co-transporting polypeptide transporters and is excreted unchanged into the bile, utilizing the bile salt export pump multidrug resistance-associated protein 2 (7). Upon irradiation with near-infrared light, ICG absorbs the light at 800 nm, emitting a strong fluorescence at a wavelength of 830 nm. This fluorescence can be digitally processed and subsequently displayed on a screen to provide accurate surgical guidance (8,9).

Rationale

In recent years, numerous applications in the field of hepatobiliary and pancreatic surgery have been described for ICG. In 2008, Aoki et al. published the first studies on fluorescence-guided surgery for performing anatomical liver resections, where the characteristics of ICG allowed intraoperative fluorescence-guided cholangiography for biliary tract identification (10). Subsequently, ICG was described as a technique for positive and negative staining in hepatic segmentectomies (11). Positive staining involves the infusion of ICG to stain the region where it has been administered, thus facilitating resection following anatomical principles. Negative staining involves vascular clamping of the hepatic region to be resected and the intraoperative administration of ICG, causing all tissue that should not be resected to illuminate, while the tissue that does not capture ICG is resected.

Furthermore, the preoperative administration of ICG has been used to identify abnormal biliary drainage (12). Since ICG must be eliminated via the biliary route, regions with abnormal drainage retain ICG and can therefore be identified intraoperatively thanks to the accumulation of this molecule in the tissues.

Objective

Based on these distribution and tissue diffusion characteristics of ICG, the objective of this video case study, is to present various applications of ICG to perform an anatomical hepatic segmentectomy. We present this article in accordance with the SUPER reporting checklist (available at https://tgh.amegroups.com/article/view/10.21037/tgh-24-156/rc).

Preoperative preparations and requirements

Following iatrogenic bile duct injury, a thorough preoperative study must be conducted to identify the cause and optimal individualized treatment for each patient. In this clinical case, the following were performed:

• Contrast-enhanced computed tomography (CT) revealed an atrophic region in hepatic segment 5, along with slight dilation of the bile duct adjacent to this segment.
• Magnetic resonance cholangiopancreatography (MRCP) demonstrated metallic clips in the B5s, which drain directly into the common bile duct and were significantly dilated.
• After the preoperative study, an endoscopic approach was attempted via endoscopic retrograde cholangiopancreatography (ERCP) to finalize the diagnosis and attempt to resolve the bile duct obstruction. The endoscopic approach failed to surpass the stenotic point, necessitating a surgical approach through open surgery.
• Preoperative administration of ICG—3 days before the surgical procedure, at a dose of 0.5 mg/kg was administered. This administration serves as a preoperative function test (ICGR15: 3.6%). Additionally, given the abnormal bile duct drainage in the affected hepatic segment, ICG could not be properly excreted from the liver, thus accumulating and theoretically helping identify the affected hepatic segment.

Based on the complementary diagnostic tests, it was decided to proceed with an S5 segmentectomy, not only resecting the damaged portion of segment 5 but also performing a complete segmentectomy to prevent recurrent episodes of cholangitis. In this case, an open approach was chosen. The history of cholecystectomy with BDI, along with multiple episodes of cholangitis, suggested the presence of significant adhesions in the surgical field. Additionally, the need for intraportal ICG injection into the S5 pedicles represented a high-risk maneuver, posing a significant technical challenge if attempted via a minimally invasive approach. Nevertheless, despite its technical complexity, a minimally invasive approach for such resections could be a safe and effective technique under certain circumstances.

The study was conducted in accordance with the Declaration of Helsinki and its subsequent amendments. Informed consent was obtained from the patient. Ethics committee approval was not required, as the procedure was part of routine clinical practice.

Step-by-step description (Video 1)

• Surgical preparation—general anesthesia and orotracheal intubation. Central line cannulation. Positioning with legs closed and arms at the sides. Thompson retractor for cephalic traction.
• L-shaped skin incision—dissection through tissue layers to access the abdominal cavity and perform exploratory laparotomy. Dissection of adhesions in the previous cholecystectomy bed. Upon naked-eye examination, atrophic regions of segment 5 were identified.
• Use of near-infrared imaging with LIGHTVISION NIR Fluorescence Imaging System, SHIMADZU, displayed on an Ikegami screen, showing an atrophic region with altered biliary drainage.
• Delimitation of the area with altered bile duct drainage using monopolar energy.
• Intraoperative ultrasound with ALOKA ProSound Alpha 7, identifying not only bile duct dilations in the atrophic area but also in the non-fluorescing zone surrounding the atrophic segment.
• To minimize the risk of postoperative cholangitis, an anatomic resection of the entire segment 5 was performed using the positive staining technique.
• Guided by intraoperative ultrasound, the medial and cranial branches of the segment 5 portal vein were punctured, followed by the injection of a staining solution consisting of 0.25 mg ICG mixed with 5 mL indigo-carmine. Segment 5 demarcation was slightly visible upon naked-eye examination. Fluorescence imaging clearly delineated the whole segment 5 to be removed with LIGHTVISION, which included the atrophic area identified at the beginning of the surgery.
• Segment 5 was then delimited using monopolar energy (Figure 1).


  Figure 1 Anatomical S5 segmentectomy. (A) Abdominal CT showing atrophic region in S5. (B) Naked-eye visualization of atrophic region. (C) Near infrared fluorescence imaging showing altered biliary drainage after preoperative ICG administration. (D) Segment 5 demarcation after positive staining with ICG and indigo-carmine. (E) State of the liver after S5 segmentectomy. (F) Anatomopathological findings of sclerosing cholangitis. Hematoxylin & eosin, ×40. CT, computed tomography; ICG, indocyanine green.
• Under Pringle maneuver, hepatic parenchyma was transected using the clamp-crash technique. During the procedure, the two major portal branches previously stained were identified and ligated. Tributaries of the right hepatic vein and the middle hepatic vein were also divided.
• The root of the dilated hepatic ducts with complete obstruction was identified and divided approximately 1 cm distal to the metal clips placed during the cholecystectomy. The biliary stump was reinforced with a 4/0 non-absorbable suture.
• The specimen was analyzed under near-infrared light, confirming the excision of the entire atrophic area.
• Fluorescence imaging was used to confirm the removal of all stained regions. Subsequently, 1.25 mg of ICG was intravenously injected to confirm blood perfusion of the remaining hepatic parenchyma via fluorescence imaging.
• No bile leaks were identified by naked-eye examination or fluorescence imaging.
• Fibrin glue was sprayed onto the hepatic raw surfaces to ensure hemostasis, and a prophylactic abdominal drain was placed.
• Anti-adhesion material was applied, and the abdomen was closed in a layer-by-layer fashion.

Postoperative considerations and tasks

The postoperative course was uneventful. The patient was discharged on day 8.

The anatomopathological report indicated the presence of sclerosing cholangitis (Figure 1).

Tips and pearls

In this novel technique of fluorescence-guided liver surgery using ICG, various utilities of this molecule have been demonstrated:

• Preoperative function test—ICG was administered preoperatively to assess liver function.
• Identification of atrophic regions—the abnormal bile duct drainage in the affected hepatic segment caused ICG to accumulate, aiding in the identification of the compromised hepatic segment (0.5 mg/kg).
• Intraoperative demarcation. Positive staining—during the surgical procedure, ICG allowed for precise intraoperative demarcation of the affected liver segments through positive staining for segment 5 demarcation (0.25 mg with 5 mL indigo-carmine). The near-infrared fluorescence imaging system enabled clear visualization of the anatomical boundaries of the hepatic segments requiring resection.
• Completion of atrophic area removal—near infrared fluorescence facilitated ensure a complete resection of the altered biliary drainage area was achieved.
• Blood perfusion assessment—post-resection, ICG was used to confirm adequate blood perfusion in the remaining hepatic parenchyma. Intravenous injection of ICG allowed for real-time assessment of liver tissue viability through fluorescence imaging, ensuring that the resected area was limited to non-viable or compromised tissue.
• Detection of bile leaks—ICG fluorescence imaging was instrumental in detecting bile leaks intraoperatively. This immediate assessment allowed for prompt surgical correction, reducing the risk of postoperative complications.
• Enhanced visualization—the integration of near-infrared fluorescence imaging with the surgical workflow provided enhanced visualization of critical anatomical structures, such as bile ducts and blood vessels, improving surgical precision and patient outcomes.
• Another possible approach would have been performing the segmentectomy using negative staining. In this particular case, where there was ICG retention in the damaged part of S5 due to preoperative ICG administration, the use of negative staining could have led to confusion. This is because distinguishing whether the observed fluorescence was due to vascularized tissue not subjected to negative staining or residual ICG retention from the preoperative administration could have been challenging.

This technique underscores the multifaceted applications of ICG in liver surgery, from preoperative planning and intraoperative guidance to postoperative assessment, thereby enhancing the safety and efficacy of hepatic resections.

Discussion

Surgical highlights

In the context of anatomical segment 5 segmentectomy, several critical steps must be meticulously followed to ensure a successful outcome. The preoperative administration of ICG at a dose of 0.5 mg/kg three days before surgery is crucial. This timing allows sufficient uptake and retention of ICG in the liver, particularly highlighting areas with compromised bile excretion (13). Accurate imaging using techniques such as contrast-enhanced CT and MRCP is essential for identifying anatomical abnormalities and planning the extent of the resection (14). During the surgery, the precision of puncturing the medial and cranial branches of the segment 5 portal vein and the subsequent injection of ICG mixed with indigo-carmine for positive staining is paramount. This step ensures the clear delineation of the hepatic segment to be resected (15). The use of the Pringle maneuver to minimize blood loss during parenchymal transection, followed by careful identification and ligation of the major portal branches, is another crucial aspect to consider (16).

Modifications and troubleshooting of the technique

Modifications to the ICG protocol may be necessary based on the patient’s liver function and the specific surgical scenario. For instance, the dosage of ICG might be adjusted in patients with impaired liver function to prevent prolonged retention and potential toxicity (17). The concentration of indigo-carmine can also be modified to enhance the visibility of stained regions. Troubleshooting may involve addressing challenges such as poor visibility of ICG fluorescence, which could be due to suboptimal lighting or technical issues with the imaging system (18). It is essential to ensure optimal conditions for near-infrared imaging, including reducing ambient light and ensuring proper calibration of the imaging equipment. In cases where positive staining does not adequately delineate the target segment, a secondary injection of ICG or adjustments to the imaging parameters may be required (19). Additionally, alternative methods such as using methylene blue dye can be considered if bile leaks are suspected but not detected using ICG fluorescence (20).

Strengths and limitations

Despite its advantages, the use of ICG fluorescence imaging in liver surgery is not without limitations. One primary concern is the variability in ICG uptake and distribution, which can be influenced by the patient’s liver function and metabolic rate (21). In patients with significant liver dysfunction, the visualization might be compromised due to inadequate excretion of ICG. Another limitation is the depth penetration of near-infrared fluorescence, which can affect the visibility of deeper structures within the liver. This limitation may result in the incomplete identification of lesions or abnormalities located deep within the hepatic parenchyma (22). Moreover, there is a risk of false positives or negatives, particularly in detecting bile leaks or identifying compromised tissue. For example, areas with retained ICG may not always correspond accurately with diseased tissue, potentially leading to incomplete resection or unnecessary removal of healthy tissue (23).

Comparison with other surgical techniques and researches

ICG fluorescence imaging represents a significant advancement over traditional methods in hepatobiliary surgery. Unlike standard visual inspection or conventional imaging techniques, ICG provides real-time, intraoperative guidance, allowing for dynamic assessment of tissue perfusion and immediate detection of bile leaks (24). This capability enhances the precision of surgical interventions, reducing the likelihood of postoperative complications. The ability to clearly delineate anatomical boundaries using ICG fluorescence is particularly beneficial compared to relying solely on anatomical landmarks, which can be unreliable due to variations or previous surgical modifications (25). The real-time feedback offered by ICG imaging facilitates more accurate and safer resections, thereby improving overall surgical outcomes (26).

Implications and actions recommended

The potential future applications of ICG fluorescence imaging in liver surgery are extensive. Beyond segmentectomy, this technique could become a standard in various complex hepatobiliary procedures, including tumor resections (27-29), donor liver surgeries, and intricate biliary reconstructions (30). Its utility in visualizing bile ducts and vascular structures could be invaluable in procedures requiring meticulous dissection and reconstruction (31). Additionally, the integration of ICG fluorescence imaging with advanced technologies, such as intraoperative MRI or augmented reality systems, holds promise for even more precise and intuitive surgical guidance. Such integration could further enhance the safety and efficacy of complex surgeries, offering real-time, comprehensive views of the surgical field (32,33).

Conclusions

In conclusion, the utilization of ICG fluorescence imaging in liver surgery offers numerous benefits, including enhanced precision, real-time guidance, and improved patient outcomes. While there are some limitations, such as variability in ICG distribution and limited depth penetration, the technique’s advantages in providing dynamic intraoperative feedback and enhancing surgical accuracy are significant. As technology advances and the understanding of ICG’s applications broadens, this technique is likely to become increasingly integral to a wide range of hepatobiliary surgical procedures. Future developments could expand its use, incorporating advanced imaging modalities and personalized medicine approaches to optimize surgical interventions further.
