Endoscopic stricturotomy with pulsed argon plasma and balloon dilation for refractory benign colorectal strictures: a case series

Introduction

Benign strictures of the colon and rectum affect a sizable portion of patients who have an underlying inflammatory disease or who have undergone recent surgery. Etiologies include inflammatory bowel disease (IBD), post-surgical ischemia, anastomotic strictures, non-steroidal anti-inflammatory drugs (NSAIDs), and complicated diverticulitis (1,2).

Medical management of benign colorectal stricture is of limited utility given the fibrostenotic nature of the stricture, particularly in Crohn’s disease patients. Surgical interventions, including resection and stricturoplasty, are more effective in treating colorectal strictures than endoscopic methods, but not without risks and do not prevent future colorectal stricture recurrence. Furthermore, endoscopic treatment methods are able to space out the need for surgery by an average of 6.5 years (1). Current endoscopic treatments include balloon dilation, stenting, stricturotomy, and combined endoscopic balloon dilation (EBD) with stricturotomy or stenting with a variable success rate from 75% to 90% and recurrence rate 6–18%.

In certain cases, the stricture is very challenging to manage with the current endoscopic armamentarium. We decided to combine argon plasma coagulation (APC) and EBD as a novel therapeutic technique for refractory benign colorectal stricture in the following case series. We present the following case series in accordance with the CARE Guideline (3).

Case presentation

Patient case 1

A 56-year-old male presented to the clinic with intermittent right-sided abdominal pain for 6 months. Past medical history was significant for the 27-year history of Crohn’s disease. His maternal grandmother had colon cancer and his mother had celiac disease. He is a non-smoker and denies any alcohol or illicit drug use. He had prior use of an anti-TNF inhibitor with secondary loss of response. Current medications included azathioprine and ustekinumab injection every 8 weeks. Vital signs were normal. The abdomen was soft, non-tender, no organomegaly, normal bowel sounds, and normal rectal exam. Labs revealed hemoglobin 14.2 g/dL, leukocyte count 7 k/mm³, platelets 393 k/mm³, blood urea nitrogen 13 mg/dL, creatinine 1.0 mg/dL, CRP 0.9 mg/dL and fecal calprotectin 59 µg/g. Magnetic resonance enterography (MRE) revealed a severe short segment stricture of the mid ascending colon. He underwent a colonoscopy, and it showed a benign-appearing, severe non-traversed stricture measuring 3 cm in length ×1.1 cm in inner diameter in the ascending colon that was approximately 5 cm distal to the cecum (Figure 1). Initially, he underwent three sessions of EBD with no improvement. The decision was made to use another modality. We started with pulsed argon plasma at flow 1.5 liters/minute, Effect 2, 40 watts for tissue ablation at the stricture edge, followed by balloon dilation up to 15 mm, resulting in significant improvement in the luminal narrowing (Figure 2). The stricture was successfully traversed, and the cecum was inspected. The second colonoscopy after 4 weeks showed mild stenosis, which was traversed after 15 mm balloon dilation. Four weeks later, colonoscopy showed improvement in the stenotic segment, and it was traversed with PCF 190 (Olympus^TM) scope with no further treatment. All the interventions mentioned above were technically successful, with no complications reported. At 3 months’ follow-up, the patient was doing well, and the abdominal pain was resolved.

Figure 1 Colonoscopic image showing a benign-appearing, severe non-traversed stricture in the ascending colon.

Figure 2 Colonoscopic image showing significant improvement in the stricture after pulsed argon plasma and endoscopic balloon dilation.

Patient case 2

A 70-year-old female presented to the emergency department with worsening left groin pain, and fever over the last 3 weeks. Left groin pain had been going on for 3 months with symptoms of pneumaturia and fecaluria. She had a history of breast cancer, which was treated with lumpectomy and radiation. Family history was unremarkable. She is non-smoker and denies alcohol or illicit drug use. Her temperature as 101 Fahrenheit (F). The abdomen was soft, non-tender with left inguinal hernia without induration or overlying skin changes. Labs revealed hemoglobin 10.8 g/dL, leukocyte count 24.4 k/mm³, platelets 686 k/mm³, blood urea nitrogen 18 mg/dL, and creatinine 0.82 mg/dL. Computed tomography (CT) of the abdomen and pelvis revealed colovesical fistula, diverticulitis, and deep abdominal wall abscess. She underwent laparoscopic low anterior resection with primary colorectal anastomosis, diverting loop ileostomy, a takedown of colovesical fistula, and drainage of the abscess. Four months later, follow-up barium enema was performed and showed severe narrowing of the distal colon and remaining upper rectum, proximal and distal to the expected position of the anastomosis. Colonoscopy revealed end-to-end colorectal anastomosis at 18 cm proximal to the anus with severe stenosis (5 mm in diameter) and was not traversed (Figure 3). She failed EBD trials using 10–12 and 12–15 mm diameter and fully covered stent. Pulsed APC (same settings as the first case) combined with EBD 15–18 mm was performed, and the stricture was traversed. One month later, repeat colonoscopy showed mild stenosis. Repeat pulsed APC with EBD up to 20 mm was performed with complete resolution of luminal narrowing (Figure 4). The patient tolerated the two sets of pulsed APC and EBD with no complications reported. She was doing well at 2 months follow-up, and the plan was made to reverse the diverting loop ileostomy.

Figure 3 Colonoscopic image showing end-to-end colorectal anastomosis at 18 cm proximal to the anus with severe stenosis.

Figure 4 Colonoscopic image showing complete resolution of the anastomotic stricture after pulsed argon plasma and endoscopic balloon dilation.

Patient case 3

A 64-year-old male presented to the emergency department with a 1-day history of diffuse abdominal pain, nausea, vomiting and constipation. Six years ago, she was diagnosed with rectal adenocarcinoma and had a low anterior resection, primary anastomosis, and diverting ileostomy. He is a former smoker and denies alcohol or illicit drug use. Family history was unremarkable. Vital revealed a blood pressure of 95/63 mmHg, a pulse of 100 beats per minute, a temperature of 98.2 F, and a respiratory rate of 12 breaths per minute. The abdomen was distended, tender to percussion, without guarding or rebound tenderness. Bowel sounds were hyperactive. Labs revealed hemoglobin 11.2 g/dL, leukocyte count 9.5 k/mm³, platelets 219 k/mm³, blood urea nitrogen 37 mg/dL, and creatinine 1.98 mg/dL. CT of the abdomen and pelvis showed diffuse dilation in both large and small bowels with air-fluid levels up to the anastomotic site in the rectum. He had a history of multiple trials of endoscopic dilation and stenting for the anastomotic stricture with the last trial was 1 month before presentation with no significant improvement in the luminal narrowing. After the patient’s stabilization, flexible sigmoidoscopy was done and shown severe anastomotic stenosis in the rectum, which was 3 cm in length and 15 cm proximal to the anus (Figure 5). The stricture was biopsied and proven to be benign. It was traversed only with a diagnostic gastroscope (GIF-190 scope Olympus^TM) with mild resistance. Pulsed argon plasma at 1.5 liters/minute and 40 watts, Effect 2 (Figure 6), followed by EBD 12–15 mm, was used. The stenosis improved and was traversed using the PCF 190 colonoscope. The patient tolerated the procedure with no complications reported. The patient’s symptoms improved with the resolution of his bowel obstruction. Three months later, he was seen in the clinic and he was doing good with no acute complaints.

Figure 5 Sigmoidoscopic image showing a benign-appearing, severe anastomotic stricture in the rectum.

Figure 6 Sigmoidoscopic image showing significant improvement in the stricture after pulsed argon plasma and endoscopic balloon dilation.

Patient case 4

A 58-year-old female was found to have a sizeable villous tumor of the cecum during screening colonoscopy. Past medical history was remarkable for essential hypertension, hyperlipidemia and obesity. Her paternal grandfather had pancreatic cancer, and her mother had osteoarthritis. She is a former smoker and drinks alcohol occasionally. Vital signs were normal. The abdomen was soft, non-tender, no organomegaly, normal bowel sounds, and normal rectal exam. Labs revealed hemoglobin 12.4 g/dL, leukocyte count 9.7 k/mm³, platelets 236 k/mm³, blood urea nitrogen 8 mg/dL, and creatinine 1.0 mg/dL. She underwent laparoscopic right hemicolectomy with ileal to transverse colon anastomosis. During surveillance colonoscopy 10 years later, she was found to be having patent side-to-side ileocolonic anastomosis, healthy-appearing mucosa of the terminal ileum, and non-patent surgical ileocolonic pouch, characterized by edema and 9 mm in diameter fibrotic stricture (Figure 7). To examine the pouch, we decided to start with EBD, but it was unsuccessful. Therefore, we used pulsed argon plasma at 1.5 liters/minute, effect 2, and 40 watts with endoscopic dilation up to 12 mm (Figure 8). The pouch was examined and found to be healthy. The patient tolerated the pulsed APC with EBD with no technical difficulties or complications reported. Follow-up endoscopy 3 months later showed no residual stricture, and the pouch was entered without difficulty.

Figure 7 Colonoscopic image showing non-patent surgical ileocolonic pouch with edema and significant fibrotic stricture.

Figure 8 Colonoscopic image showing significant improvement in the stricture after pulsed argon plasma and endoscopic balloon dilation.

Discussion

Benign colorectal strictures can cause significant morbidity. They occur as a final result of inflammation cascade with resultant fibrosis. They can also be complications of several disease processes, including IBD (1,2). Moreover, their occurrence can also be seen as a result of anastomotic strictures from colorectal surgery, which occurs up to 20% of all surgeries (4).

Since 1984, the endoscopic dilation technique has become the treatment of choice for benign colorectal strictures, particularly when the stricture is secondary to post-surgical stenosis and IBD (5). Several techniques have been illustrated using dilation balloons such as wire-guided, achalasia balloon, and through the scope balloon dilation. In most cases, the technique requires multiple sessions with a gradual increase in balloon diameter until resolution of the stricture. It is an effective and safe technique with an early success rate in post-surgical stricture that reaches 100%. Still, the recurrence rate of post-surgical stricture post after dilation is high and reaches up to 25% depending on stricture length (6).

The other treatment option in the management of colorectal stricture is the use of a self-expandable metal stent. In 2015, Park et al. assessed the use of SEMS vs. dilation among 43 patients and realized no noticeable difference in resolution of stricture between two treatment modalities (5). Lately, stents made from biodegradable materials called biodegradable stents have been used in the treatment of benign post-surgical strictures. These stents need rigid guide wires for deployment, and it is useful only for distal colon stricture with least 9.4 mm caliber because the width of the release system is 28 F, and length is 75 cm (7). The main disadvantage is early stent migration (7). There is no substantial evidence about the use of biodegradable stents in the management of benign colonic stricture.

Another treatment called endoscopic electrocautery incision (EEI) has been used for the treatment of benign anastomotic colorectal strictures. Different techniques have been described using an IT knife, hook knife, scissor-type knife, sphincterotomes, or polypectomy snares. One technique is to combine EEI with argon plasma to clean the tissue between the radial incisions (8). It has been suggested that EEI is a safe and effective treatment option for short refractory benign strictures (9,10). Bleeding is the primary concern using this therapy, especially intraprocedural. Recently, Lumen-apposing metal stents have been used in the treatment of benign post-surgical anastomotic stricture with promising results and low migration rates (11). However, the efficacy of these stents varies by the location of the stricture.

In our study, we used a novel combined technique of argon plasma and EBD among four patients with benign colonic strictures (three post-surgical and one due to Crohn’s disease). The technical success defined as a satisfactory application of endoscopic dilation and argon plasma with no difficulty, and early clinical success defined as resolution of the symptoms or being able to traverse the stenotic stricture to examine the proximal colon) were 100%. No complications were reported from this approach (Table 1).

Traditionally, APC was invented as a remote coagulation technique for the management of superficial bleeding, neoplasms of gastrointestinal, and respiratory tracts (12-15). The unique character of this technique is the ability to deliver high-frequency electrical current via the ionized argon gas without touching the ablation site. Argon is chemically inert with a bright, shining color that can be pointed under visual guidance. The ionized argon plasma has a constant depth of penetration, which is 2 mm.

We adopted this technique from post gastric sleeve leak endoscopic therapy (16). The first step is a careful examination of the stricture and adequate position of the scope to place the stricture at the center. Then, we use the APC probe (APC; ERBE USA Incorporated, Marietta, Georgia, USA) after it was connected to ERBE generator VIO 300D. The settings are pulsed APC at flow 1.5 liters/minute, Effect 2, 40 watts. The tissue dissection starts via using the pulsed APC at one side of the stricture with close contact and slowly advance through the stricture in a perpendicular fashion, followed by EBD using 12–15 mm and gradually increase the size up to 20 mm. CO₂ is essential for these cases, and no fluoroscopy required. APC is useful in desiccation of the stricture, thus promoting hemostasis and preventing perforation. To our knowledge, combining APC with EBD technique has not been reported in the literature. We believe that combined APC with EBD is a safe and effective technique in the treatment of benign colonic stricture.

The limitations of our study are retrospective design with it is inheritance, a small sample size of only four patients, and short follow-up (3 months) duration that didn’t allow us to identify long-term functional outcomes.

In conclusion, there are no established guidelines on how to approach patients with benign colorectal strictures. EBDs have been suggested as the first therapeutic modality. The combined technique using APC with EBD is safe and effective in treating patients with benign colorectal strictures. The procedure is reproducible and can be performed in an outpatient setting. Larger studies with longer follow-up periods are needed to validate further the long-term effectiveness and safety of this novel therapeutic technique and to compare it with other standard therapies.
